رله هوشمند 24 کانال برند INTERRA

مشخصات فنی رله هوشمند 24 کانال برند INTERRA

رله هوشمند 24 کانال برند INTERRA دارای مشخصات زیر می‌باشد.

technical Power

supply data : EIB

power consumption max .: 0.3W

Outputs: 24

Commissioning mode: S-Mode

Degree of protection: IP20 Operating

temperature range: – 10 to 70 degrees Celsius

Storage: – 25 to 100 degrees Celsius

Max. Humidity: <90 RH

Non-combustible product

Installation: DIN rail

Dimensions WxHxD: 274 x 90 x 64 mm, 15 DIN units

Certification: EIB certification

Max. Connected load : 16A @ 250V AC, C load (140µF)

Inrush current: 165A

– incandescent lamps 2300 W

– HV halogen lamps 2300 W

– fluorescent tubes uncompensated 1000 W

– fluorescent tubes connected in parallel 1500 W, 140µF

– compact fluorescent lamp, 20 lamps max, 400W max

– LED 20 lamps max, 400W max

– NV halogen lamps VVG or EVG 1500 W

– fluorescent tubes with electronic ballast (mono + duo) 1000 W

– blind motors (cos phi = 0.6) 6A

– Fan-Coil Motors (cos phi = 0.6) 4A

certification: EIB certification
